2022 Harley-Davidson Sportster S

Stock #23-001

119 people have recently viewed it.
Check Availability Hi, my name is and I'm interested in this 2022 Harley-Davidson Sportster S . I'm in the area and you can reach me at or by phone at .





DESCRIPTION



Sportster® S is the first chapter of a whole new book of the Sportster saga. A legacy born in 1957 that outperformed the competition is now rebuilt to blow away the standards of today.

  • Stretched riding position
  • Forward foot controls
  • Low
  • Rider safety enhancements available

THIS IS THE RIGHT BIKE FOR

  • Riders who desire top-of-the-line performance and stunning style
  • Aggressive riding with sport bike agility and handling
  • Making a statement and standing out from the crowd



ALL-NEW REVOLUTION® MAX 1250T

The next chapter in a century of legendary V-Twins is here. Revolution® Max is a liquid-cooled powertrain with double overhead camshafts and variable valve timing: offering ample torque and an immediate powerband tuned to maximize rider control.


HIGH MOUNT EXHAUST

Inspired by the glory days of H-D flat-track racing, the pipes are crafted from corrosion-resistant 304-series stainless steel and engineered to deflect exhaust heat away from the rider’s legs and tail section.


CLASSIC MEETS MODERN: 4” ROUND DISPLAY

Everything you need to know is housed in a Bluetooth®-equipped, 4” round thin-film transistor LCD display: digital gauges, indicators, ride modes, and turn-by-turn navigation with the Harley-Davidson® app. All functions are accessed via buttons on the left- and right-hand controls.


CHOOSE YOUR RIDE MODE

Flick a switch and choose from 3 pre-programmed Ride Modes (Sport, Road, and Rain) or create your own custom mode?— tuning your bike with a specific combination of power delivery, engine braking, Cornering Enhanced Antilock Braking System (C-ABS) and Cornering Enhanced Traction Control System (C-TCS) settings


DUAL PURPOSE POWERTRAIN

The Revolution® Max 1250T is a structural component of the motorcycle chassis, eliminating a traditional frame —?which significantly reduces overall weight and keeps handling precise. This is performance you can feel, with the center of gravity low and the chassis super rigid.


MAKE IT YOUR OWN

Harley-Davidson® Parts & Accessories offers new ways to take your Sportster® S to a whole new level. Mid-control kit for comfort and style. Engine guard and quick release windshield deflect the elements. Pillion and backrest for two-up riding, and a sleek tailbag for essentials. The Wild One™ Collection is designed to thrill, every piece tailored to the bike, so it fits and works and looks just right.



SPORTSTER® S FEATURE HIGHLIGHTS

  • Revolution® Max 1250T Powertrain
  • 94 ft. lbs. Torque
  • 121 Horsepower
  • Weight (As Shipped/Running Order): 487/502 pounds
  • 4-inch Round TFT Display Screen
  • Bluetooth® Connectivity and Moving Maps Navigation
  • Cornering Rider Safety Enhancements including ABS and Traction Control
  • Selectable and Customizable Ride Modes
  • All LED Lighting Adjustable Performance Suspension
  • Cruise Control
  • Status:
    New
  • Vehicle:
    2022 Harley-Davidson Sportster S
  • VIN:
    1HD1ZC425NB326152
  • Model Number:
    RH1250S
  • Mileage:
    5 miles
  • Color:
    Vivid Black
  • Stock Number:
    23-001
  • Title:
    Clear
  • Location:
    Quaid Harley-Davidson, Loma Linda, CA 92354
  • Warranty:
    Manufacturer's w/ Extended Available

AUDIO & COMMUNICATION

  • Bluetooth® Audio:
    Yes
  • Mobile App Instrumentation:
    Yes

BRAKES

  • Front Brake Diameter (in):
    12.6
  • Front Brake Diameter (mm):
    320
  • Front Brake Type:
    Hydraulic Disc
  • Rear Brake Diameter (in):
    10.2
  • Rear Brake Diameter (mm):
    260
  • Rear Brake Type:
    Hydraulic Disc

ENGINE

  • Bore (in):
    4.13
  • Bore (mm):
    104.9
  • CAN Liters Per Kilometer (Combined):
    4.8
  • Carburetion Type:
    Fuel Injected
  • Compression Ratio:
    12
  • Cooling:
    Liquid
  • Cylinders:
    2
  • Displacement (cc):
    1252
  • Displacement (ci):
    76.4
  • Engine Brand Name:
    Revolution® Max
  • Engine Stroke:
    4-Stroke
  • Engine Type:
    V Twin
  • Fuel Injector:
    Yes
  • Fuel Requirements:
    Regular
  • Fuel Type:
    Gas
  • Horsepower (bhp):
    121
  • Horsepower (kW):
    90
  • Horsepower RPM:
    7500
  • Starter:
    Electric
  • Stroke (in):
    2.85
  • Stroke (mm):
    72.4
  • Torque (Ft Lbs):
    94
  • Torque (Nm):
    127.4
  • Torque RPM:
    6000
  • US Miles Per Gallon (Combined):
    49
  • Valve Configuration:
    DOHC

EXTERIOR

  • Belt Guard:
    Yes
  • Exhaust Guard:
    Yes
  • Foot Peg Location:
    Driver
  • Frame:
    Steel
  • Stand Type:
    Kick

GLASS

  • Folding:
    Yes

INSTRUMENTATION

  • Fuel Level Warning Type:
    Gauge
  • Temperature Warning Type:
    Light

LIGHTS

  • Type:
    LED

SEATS

  • Number Of Seats:
    1
  • Seat Height (in):
    29.6
  • Seat Height (mm):
    751.8
  • Seat Location:
    Driver
  • Seat Type:
    One-Piece

STEERING

  • Steering Control:
    Handlebar

SUSPENSION

  • Front Adjustable Fork Pre-Load:
    Yes
  • Front Adjustable Rebound Damping:
    Yes
  • Front Suspension Brand Name:
    Showa®
  • Front Suspension Size (in):
    43
  • Front Suspension Size (mm):
    1092.2
  • Front Suspension Type:
    Inverted Fork
  • Number Rear Shock Absorbers:
    1
  • Rear Adjustable Rebound Damping:
    Yes
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Suspension Brand Name:
    Showa®
  • Rear Suspension Material:
    Steel
  • Rear Suspension Type:
    Twin Sided Swing Arm

TECHNICAL SPECIFICATIONS

  • Dry Weight (kg):
    220.9
  • Dry Weight (lbs):
    487
  • Engine Displacement to Weight (cc):
    2.58
  • Fuel Capacity (gal):
    3.1
  • Fuel Capacity (l):
    11.7
  • Ground Clearance (in):
    3.5
  • Ground Clearance (mm):
    88.9
  • Length (ft):
    7.45
  • Length (ft/ft):
    7
  • Length (ft/in):
    5.4
  • Length (in):
    89.4
  • Length (mm):
    2270.8
  • Wet Weight (kg):
    227.7
  • Wet Weight (lbs):
    502
  • Wheelbase (in):
    59.8
  • Wheelbase (mm):
    1518.9

TRANSMISSION

  • Gear Ratio (1):
    12.21
  • Gear Ratio (2):
    9.022
  • Gear Ratio (3):
    6.994
  • Gear Ratio (4):
    5.641
  • Gear Ratio (5):
    4.731
  • Gear Ratio (6):
    4.131
  • Number Of Speeds:
    6
  • Primary Drive (Rear Wheel):
    Belt
  • Transmission Type:
    Manual

WHEELS & TIRES

  • Front Tire (Full Spec):
    Dunlop® Harley-Davidson Series 160/70 TR17 73V
  • Front Tire Aspect Ratio:
    70
  • Front Tire Speed Rating:
    V
  • Front Tire Width:
    160
  • Front Wheel Diameter:
    17
  • Rear Tire (Full Spec):
    Dunlop® Harley-Davidson Series 180/70 R16 77V
  • Rear Tire Aspect Ratio:
    70
  • Rear Tire Speed Rating:
    V
  • Rear Tire Width:
    180
  • Rear Wheel Diameter:
    16
  • Tire Brand:
    Dunlop®
  • Wheels Composition:
    Aluminum
